Description
PNT240 Articulated truck mounted platform
PNT240 is an articulated truck mounted platform with 24 meters of working height made by ISOLI in Italy. This lifting platform is articulated and provides bridging ability. This feature provides high maneuver in city maintenance operations. Strenx steel is used to build the structure of this aerial work platform, making it sturdy and light enough to be installed on heavier than 3.5 ton trucks. Customers can order either aluminum or fiberglass platform based on their needs and preferences.
This access platform is made precisely with highest quality material. Robotic welding is done on the boom. Chains and cables on this work platform are all placed inside the mast to increase durability and lifespan. Moment control system, anti-smash system, overweight sensor, proportional control, and digital troubleshooting system provides safety for the operator as well as the vehicle. High maneuver is one of the benefits of this articulated lift.
High maneuver and bridging ability of this access platform make it popular among lifting platform rental companies. This articulated aerial work platform is equipped with rotating platform with 90° rotation in each direction. The light weight of this articulated truck mounted platform makes it safe for the truck and will not cause any damage in the long run. This aerial work platform has 1 year warranty and 10 years of services, provided by CLAIER.
Other Features
- Made in Italy
- Stenx boom made by durable steel
- Sandblast, paint primer and electrostatic paint
- Telescopic hydraulic lifting system
- Completely proportional hydraulic control system
- Truck used as the PTO source
- Mast rotation without getting out of range
- 90° + platform rotation
- Horizontal reach limiting system based on platform weight
- Wind resistance up to 12.5 m/s
- Truck on/off switch from lift’s platform
- Oil filtering system in high pressures
- Hour counter
- Power outlet with earth system on the platform
- Designed and manufactured based on latest BSEN:280 standards
- CE and ISO certificates
Warranty and services:
- 1 year warranty
- 10 years of services
Safety Features:
- Automatic balance system for the platform
- Anti-lifting in case side jacks are not placed properly
- Anti-overweight system
- Anti-smash sensors
- Locking systems on hydraulic jacks
- Safety belt installation placement on the platform
- Anti-slipping checkered plate on the platform
- Emergency pump for lowering the device in case of emergency
- Emergency stop button in case of emergency
Optional Features:
- Fiberglass platform
- Proper piping for pressure air and water
- Projectors on the platform for working at night
- Rolling light on the Truck cabin
- 220V helper electric pump for indoor activity
- Special mats for under the side jacks
- Automatic side jack placement system
Warning: Options mentioned above may differ due to safety or quality upgrade. Call our specialists for more info.
Uses
PNT240 is one of ISOLI’s best sellers, due to its 24 meter working height, 250 kg capacity and bridging ability. This hydraulic lifting platform is a perfect option for city maintenance and reaching traffic cameras. The bridging ability and horizontal reach of this articulated truck mounted platform prevents many traffic accidents and providing safety for the operators and technicians. This access platform is also commonly used in oil refineries and petrochemicals. Doing overhauls and seasonal repairs, Painting jobs, welding, piping, etc. High safety level of this articulated lift is accepted by HSE units and all accidents are at a minimum.
This truck mounted lifting platform is a safe option for electricity distribution companies and their contractors. Price of this articulated lift is higher than Iranian version but because of the high quality and safety systems as well as easy maintenance, it is logical to consider this lifting platform as an option.
